Alimentatore MEAN WELL
Brand: MEAN WELL -
Code:S-25-12
| Combination name | Availability | Price |
|---|---|---|
Switching Power Supply 25 W 12 V DC – MEAN WELL S-25-12
The S-25-12 is a single output switching power supply 25 W / 12 V DC (“Single Output Switching Power Supply”) manufactured by MEAN WELL. It belongs to the S-25 series, featuring a universal AC input of 85–264 V AC (or 120–370 V DC) and a regulated output of 12 V DC / 2.1 A. It is documented as a component in CNC control cabinets, industrial automation systems, and electronic equipment in general. The unit is fanless (natural convection cooling) and compliant with CE/UL standards. The output voltage is adjustable via an onboard trimmer in the 10–13 V range; no significant revision variants exist in the standard version.
The S-25-12 provides the regulated 12 V DC auxiliary supply required to power logic boards, relays, transducers, displays, and other subsystems inside the CNC control cabinet. A failure results in loss of voltage across all 12 V circuits: the machine stops, drives lose their auxiliary supply, and the CNC cannot complete the enable sequence. In many control cabinets it is a critical, non-redundant component.
MEAN WELL is a Taiwanese switching power supply manufacturer founded in 1982, now one of the world’s leading suppliers with over 10,000 catalog models and worldwide distribution. The S-25 series is actively produced and widely available from major global electronics distributors.
Main Technical Specifications
| Type | Single output switching power supply (Single Output SMPS) |
| Part number | S-25-12 (S2512) |
| Brand | MEAN WELL |
| Known application | CNC control cabinets, industrial automation, electronic equipment |
| Function | Regulated 12 V DC auxiliary supply for logic and control circuits |
| Input voltage | 85–264 V AC / 120–370 V DC (universal) |
| Output voltage | 12 V DC (adjustable 10–13 V via trimmer) |
| Output current | 2.1 A nominal |
| Output power | 25.2 W |
| Efficiency | ~78% (typical at full load) |
| Protections | Over-current, over-voltage, short-circuit |
| Cooling | Natural convection (fanless) |
| Interfaces / connectors | Screw terminal blocks on AC input and DC output side |
| Weight | ~0.2 kg |
| Dimensions | 99 × 82 × 30 mm |
| Production status | Active production — available from stock |
