MITSUBISHI-FREQROL Inverter
Brand: MITSUBISHI -
Cat: Inverter
Code:FR-Z024-0.75K
| Combination name | Availability | Price |
|---|---|---|
Freqrol Inverter 0.75 kW – MITSUBISHI FR-Z024-0.75K
The FR-Z024-0.75K is a variable frequency drive (inverter) from the FREQROL FR-Z series (“Frequency Inverter” / “Variable Frequency Drive”) manufactured by Mitsubishi Electric, rated for 0.75 kW three-phase AC induction motors. The unit belongs to the 200–240 V voltage class and is documented for applications in CNC machine tools and industrial equipment requiring electronic speed control of AC motors. No accessory revisions or documented variants are known; the part number identifies a single nameplate configuration.
The inverter converts fixed-frequency mains power into a variable-frequency, variable-voltage three-phase output, enabling stepless speed control of an AC induction motor. On a CNC machine tool it typically drives auxiliary spindles, coolant pumps, hydraulic units, or other accessory drives. Inverter failure immediately stops the driven device, interrupting the machining cycle or disabling critical machine functions.
Mitsubishi Electric is a Japanese multinational of the Mitsubishi Group and one of the world’s leading industrial automation manufacturers. Its Factory Automation division produces FREQROL inverters, MELDAS / MELDASMAGIC CNC systems, and MELSERVO servo drives. The FR-Z series is legacy / discontinued, superseded by the more modern FR-E, FR-A, and FR-F series; spares are available only as used, NOS surplus, or through specialist repair.
Main Technical Specifications
| Type | Inverter / Variable Frequency Drive (VFD) |
| Part number | FR-Z024-0.75K (FRZ024075K) |
| Brand | Mitsubishi Electric – FREQROL FR-Z series (legacy) |
| Known application | CNC machine tools, industrial equipment, auxiliary drives (pumps, spindles, hydraulic units) |
| Function | AC three-phase motor speed control via variable frequency and voltage |
| Applicable motor power | 0.75 kW (1 HP) |
| Input voltage | Single-phase or three-phase 200–240 V AC, 50 / 60 Hz (200 V class) |
| Output voltage / current | Three-phase 200–240 V AC, ~4–5 A rated |
| Output frequency | 0–120 Hz (typical), adjustable via parameters |
| Control method | V/f (voltage / frequency) control |
| Interfaces / connectors | Terminal strips for mains input, motor output, analogue and digital control signals; front-panel operator keypad for parameter setting |
| Weight | ~1.0–2.0 kg |
| Dimensions (W×H×D) | ~120 × 230 × 130 mm |
| Production status | Legacy / discontinued — used / surplus / repair only |
