FANUC Color Monitor 14"
Brand: FANUC -
Cat: Monitor
Code:A61L00010074
| Combination name | Availability | Price |
|---|---|---|
14″ Colour CRT Monitor – FANUC A61L-0001-0074
The A61L-0001-0074 is a 14″ colour cathode-ray tube (CRT) monitor (“14″ Colour CRT Monitor”) manufactured by FANUC, used as the integrated display unit in MDI/CRT operator consoles of FANUC Series 0, Series 6, Series 10/11/12, Series 15 and Series 16/18/21 CNC systems, as well as selected FANUC robot cells of the same era. The unit receives the video signal from the control unit via dedicated cabling and a proprietary connector, rendering all CNC operator screens in colour CRT technology. No distinct hardware revisions with separate part numbers are documented; production batches may differ only in minor internal components.
The monitor is the primary visual interface between the operator and the CNC system: without it, it is impossible to view part programmes, machine parameters, diagnostics, or alarm messages. A monitor fault effectively halts machine operation even when the control electronics are fully intact, making it impossible to interact with menus, reset alarms, or modify critical parameters.
FANUC (Fuji Automatic NUmerical Control) is the world’s leading manufacturer of CNC systems and industrial robotics, headquartered in Oshino, Yamanashi, Japan. Founded in 1956 as a division of Fujitsu and independent since 1972, FANUC holds the highest global market share in the CNC sector. CRT monitors of the A61L family are legacy / discontinued: CRT technology is no longer manufactured industrially and these components are available exclusively as used, surplus, or via replacement with compatible LCD retrofit kits.
Main Technical Specifications
| Type | 14″ Colour CRT Monitor for CNC systems |
| Part number | A61L00010074 |
| Brand | FANUC |
| Known application | FANUC CNC Series 0, Series 6, Series 10/11/12, Series 15, Series 16/18/21; FANUC robots |
| Function | Operator interface display: part programmes, machine parameters, diagnostics, alarms |
| Display technology | Colour CRT (Cathode Ray Tube) |
| Screen size | 14″ (approx. 355 mm) diagonal |
| Resolution | ~640 × 480 pixels |
| Video signal | Analogue RGB / FANUC proprietary signal |
| Power supply | ~100–240 V AC, 50/60 Hz |
| Interfaces | FANUC proprietary connector on rear panel; dedicated cabling to CNC rack |
| Weight | ~8–14 kg |
| Dimensions | ~380–430 × 300–360 × 380–450 mm W × H × D |
| Production status | Legacy / discontinued — used/surplus/LCD retrofit only |
