Brushless Servo Drive SUPER – SANYO DENKI PE0A015MXXXC00

The PE0A015MXXXC00 is a brushless servo drive (“Brushless Servo Amplifier”) from the SUPER series manufactured by SANYO DENKI. Designed to drive brushless (BL) motors in high-precision motion control applications, the drive integrates speed and current regulation loops in a compact module. The “015” code identifier indicates a nominal continuous current of approximately 1.5 A (peak typically up to 4.5 A), suitable for light or auxiliary axes on CNC machines and industrial automation systems. The “XXX” suffix indicates that certain options — typically bus version, encoder resolution or supply voltage — were selectable at the time of ordering.

The brushless servo drive closes the current and speed loop on the axis motor: it receives the speed or torque reference from the CNC controller, reads feedback from the motor-mounted encoder, and regulates phase current to follow the programmed path with minimum deviation. In the event of failure the affected axis becomes immobilised or uncontrolled, making it impossible to execute any machining operation involving that axis.

SANYO DENKI is a Japanese manufacturer founded in 1927, specialised in motion control systems (brushless servo motors and drives, industrial fans and precision cooling systems). The SUPER BL series has been widely adopted in CNC machine tools, robotic systems and factory automation. Some versions of this series are legacy / discontinued: availability should be confirmed using the full part number (specific options in place of “XXX”).

Main Technical Specifications
