MITSUBISHI Servo Drive
Brand: MITSUBISHI -
Cat: Servo Drive
Code:MR-J2-70A
| Combination name | Availability | Price |
|---|---|---|
700 W AC Servo Drive – MITSUBISHI MR-J2-70A
The MR-J2-70A is a 700 W AC servo amplifier (“AC Servo Amplifier”) from the MELSERVO-J2 series manufactured by Mitsubishi Electric. It provides position, speed, and torque control of AC servo motors, accepting pulse train input for positioning mode and a ±10 V analogue reference for speed/torque modes. It is compatible with HC-KFS and HC-MFS family servo motors of the J2 series. The CN3 connector enables parameter configuration via RS-232C or RS-422 and real-time status monitoring.
The servo drive is the component that closes the control loop between the CNC controller and the servo motor: it receives the position or speed reference, reads the encoder feedback, and generates the current required to move the machine axis with precision. A failure of the MR-J2-70A results in the immediate stop of the controlled axis, rendering the machine inoperable: no motion can be performed without a functioning drive.
Mitsubishi Electric is a Japanese company with over a century of history in industrial automation and motion control. The MELSERVO-J2 series was one of the most widely deployed servo platforms of the 1990s and 2000s on CNC machines, robots, and automation systems worldwide. The J2 family is now legacy / discontinued, progressively replaced by the J2S, J3, J4, and J5 series: availability is limited to the used, surplus, and specialist repair market.
Main Technical Specifications
| Type | AC Servo Drive – AC Servo Amplifier |
| Part number | MR-J2-70A (MRJ270A) |
| Brand | Mitsubishi Electric |
| Known application | CNC machines and industrial automation systems with MELSERVO J2-series motors (HC-KFS, HC-MFS) |
| Function | AC servo motor position, speed, and torque control |
| Rated output | 700 W (0.7 kW) |
| Power supply | 3-phase / single-phase 200–230 V AC, 50/60 Hz |
| Rated output current | ~5.0 A (peak ~15 A) |
| Operating modes | Position (pulse train), Speed (±10 V analogue), Torque |
| Encoder feedback | J2-series incremental encoder (HC-KFS, HC-MFS); resolution 16,384 p/rev |
| Interfaces | CN1 (command / I/O), CN2 (motor encoder), CN3 (RS-232C / RS-422 parameter setup) |
| Weight | ~1.5–2.0 kg |
| Dimensions | ~135 × 170 × 155 mm |
| Production status | Legacy / discontinued — used / surplus / repair only |
