FANUC Monochrome Monitor 9"
Brand: FANUC -
Cat: Monitor
Code:A61L-0001-0093
| Combination name | Availability | Price |
|---|---|---|
9″ Monochrome CRT Monitor – FANUC A61L-0001-0093
The A61L-0001-0093 is a 9″ monochrome CRT monitor (“9-inch Monochrome CRT Display”) manufactured by FANUC, used as the standard operator display unit in FANUC CNC Series 0, Series 6, Series 10/11/12 and Series 15 control systems. The monochrome phosphor cathode ray tube display (typically green P31 or amber P39) renders the CNC operator interface: active programs, machine status, alarm messages and axis coordinates. It connects to the control unit via the dedicated video board housed in the FANUC cabinet. It carries no independent CNC logic and is a pure display peripheral.
The CRT monitor is the primary operator interface of the numerical control: without it the operator cannot view the running program, read alarm messages, check axis coordinates or interact with the CNC through the keypad. A failed monitor renders the machine operationally unusable, blocking all production, diagnostic and setup activities and causing an immediate production stoppage.
FANUC is the world leader in CNC systems, industrial robots and factory automation, founded in Japan in 1956 as a Fujitsu division and independent since 1972. This monitor belongs to the classic display line for CNC systems of the 1980s–1990s and is legacy / discontinued: available only as used, surplus stock or through specialist CRT repair services and LCD retrofit kits.
Main Technical Specifications
| Type | 9″ Monochrome CRT Monitor (9-inch Monochrome CRT Display) |
| Part number | A61L-0001-0093 (A61L00010093) |
| Brand | FANUC |
| Known application | FANUC CNC Series 0, Series 6, Series 10/11/12, Series 15; machining centres and CNC lathes 1980s–1990s |
| Function | CNC operator interface display: programs, alarms, axis coordinates, machine status |
| Screen diagonal | 9″ (inches), cathode ray tube (CRT) |
| Display type | Monochrome phosphor (green P31 or amber P39, typical) |
| Video signal | Composite video / TTL from FANUC cabinet video module |
| Power supply | ~100–240 V AC (typical for industrial CRT); powered from CNC cabinet |
| Interfaces / connectors | Dedicated FANUC video connector; power cable from cabinet; no standard VGA input |
| Weight | ~4–7 kg |
| Dimensions | ~280–330 mm W × 250–300 mm H × 310–390 mm D |
| Production status | Legacy / discontinued — used/surplus/repair or LCD retrofit only |
