Digital Position Readout (DRO) – ACU-RITE III

The ACURITEIII is a digital position readout (“Digital Readout” – DRO) from the ACU-RITE® III series, manufactured by ACU-RITE (USA). It is a 2- or 3-axis display unit designed for manual and semi-automatic machine tools including milling machines, lathes, and grinding machines. The system receives position signals from linear encoders or glass scales, processes them, and displays machine axis coordinates in real time on an LED segment or LCD display. It incorporates basic calculation functions: axis zeroing, backlash compensation, bolt-hole circle calculation, and metric/imperial unit switching.

The digital position readout is the instrument that allows the operator to know at all times the exact position of the machine axes relative to the work zero point. Without the DRO the operator must rely on the mechanical verniers of the lead screws, with a typical inaccuracy of 0.05–0.1 mm; a faulty readout results in the loss of dimensional accuracy of machined parts and a significant increase in cycle times.

ACU-RITE is a US company founded in Jamestown (NY), historically specialised in precision scales and DRO systems for machine tools. Acquired by HEIDENHAIN (Germany) — a world leader in position measurement systems — ACU-RITE products continue to be distributed as a dedicated line for the manual and retrofit machine tool market. Models in the III series are legacy / discontinued, superseded by newer generations (200S, 300S series, etc.).

Main Technical Specifications

ASROBICON Servo Drive Module – ANSALDO SPDM 260RGE

The SPDM 260RGE is a digital servo drive module (“Servo Drive Module”) from the ASROBICON series, manufactured by ANSALDO Automazione (Italy). The unit is designed for digital control of servo motors in industrial CNC systems, with integrated current and speed regulation loops. The commercial alternative part number is SPDM 260RGE (internal article code SPDM260RGE). The module may be available in multiple revisions or electrical configuration variants; always verify compatibility with the installed control system before replacement.

The ASROBICON drive is the active core of the axis or spindle control loop: it receives digital references from the CNC, regulates in real time the current delivered to the servo motor, and maintains position and speed accuracy throughout the machining cycle. A failure in this module causes the immediate and uncontrolled stop of the associated axis or spindle, rendering the machine inoperable until the unit is replaced or repaired.

ANSALDO is a historic Italian industrial group with roots dating back to the 19th century, active in automation, railway traction, energy, and defence. The ANSALDO Automazione division produced CNC systems, digital drives, and servo motors for machine tools for decades, serving both the Italian and international markets. The ASROBICON series represented ANSALDO’s flagship digital drive range. These products are now legacy / discontinued: available exclusively as used stock, NOS surplus, or through specialist repair centres.

Main Technical Specifications

Switching Power Supply – ASTEC LPT43

The LPT43 is a multi-output switching power supply unit (“Switching Power Supply Unit”) manufactured by ASTEC, belonging to the LPT series, designed to power control boards, operator interfaces and peripherals in CNC machine tools and industrial automation systems. The unit converts mains voltage into multiple regulated DC voltages (typically +5 V, ±12 V and +24 V DC) using high-frequency switching technology, delivering high efficiency, low ripple and protection against overload. It is not a conventional linear supply but a compact SMPS module with multiple independent outputs.

The power supply is the energy core of the CNC control cabinet: it provides all electronic boards with the service voltages without which no axis, no I/O and no interface can operate. A fault in the LPT43 causes the immediate shutdown of the entire machine; typical symptoms range from failure to power on to spontaneous resets, intermittent voltage errors and erratic axis behaviour under load.

ASTEC International was founded in 1975 as a pioneer in switching power supplies for the electronics and automation industries. Acquired by Emerson Electric, the products were absorbed into Emerson Network Power; the division subsequently became Artesyn Technologies (2014) and finally part of Advanced Energy Industries (2019). All products in the LPT series are legacy / discontinued: available exclusively as used, NOS or through specialist repair.

Main Technical Specifications

Switching Power Supply – ASTEC LPT42

The LPT42 is a compact switching power supply (“Switching Power Supply”) manufactured by ASTEC International, belonging to the LPT series of high-efficiency compact switching power supply modules. The unit converts AC mains voltage into multiple regulated DC outputs, typically +5 V, ±12 V and +24 V, intended to power the electronic control boards in CNC control cabinets and industrial automation systems. The LPT series is noted for its compact form factor and universal input range, which led to its widespread adoption across a broad range of machine tools and measurement systems throughout the 1980s and 1990s.

The power supply is the energy core of the CNC control system: without it, no electronic board — CPU, axis drives, I/O modules — receives the voltage required to operate. A power supply failure results in an immediate total machine shutdown; out-of-tolerance output voltages or excessive ripple can also cause intermittent malfunctions that are difficult to diagnose and may damage downstream boards.

ASTEC International (founded in 1970 in Hong Kong) was a pioneer in industrial switching power supplies, with an extensive product range covering automation, telecommunications and computing. Acquired by Emerson Electric, the product line was absorbed into Emerson Network Power and subsequently into Artesyn Embedded Technologies. Many models in the LPT series are legacy / discontinued: available only as NOS (New Old Stock), used, or through specialist repair.

Main Technical Specifications

Multi-Output Switching Power Supply – ASTEC LPQ113

The LPQ113 is a multi-output switching power supply (“Multi-Output Switching Power Supply”) manufactured by ASTEC, used as the main power unit in CNC controllers and industrial automation systems from various machine builders. The module delivers the regulated DC voltages required by logic boards, control circuits and system interfaces. The ASTEC reference code is LPQ113; no documented alternative codes or known revisions are recorded for this item.

The power supply is the central element of the energy distribution system within the CNC controller: it converts the mains voltage into regulated low-voltage outputs (+5 V, ±12 V and, typically, one or more auxiliary rails) essential for the correct operation of CPUs, memories, I/O boards and communication circuits. A power supply failure immediately results in the inability to start the machine or in hard-to-diagnose operating faults, causing unplanned machine downtime.

ASTEC International (Advanced Switching Technology) is a long-established manufacturer of switching power supplies for industrial, telecommunications and embedded applications, founded in Hong Kong in the 1970s. Acquired by Emerson Network Power, the business subsequently became part of Artesyn Technologies (now part of Advanced Energy Industries). All products in the LPQ series are legacy / discontinued: available only as used stock, surplus or through specialist repair.

Main Technical Specifications

Digital Compact Servo Drive – BAUMÜLLER BKF12/50/400-2002

The BKF12/50/400-2002 is a digital compact servo drive (“Digital Compact Servo Drive”) from the BKF series, manufactured by Baumüller, designed to control synchronous and asynchronous AC servo motors in advanced industrial automation applications. The unit is typically installed in CNC machine tools, injection moulding machines for plastics, textile machines, and printing machinery equipped with Baumüller drive systems. It closes the current, speed, and position control loops, interfacing with the numerical controller via analogue speed reference and digital I/O. The suffix -2002 identifies a specific hardware/firmware revision of the series.

The servo drive is the heart of the axis motion system: it receives the position or speed reference from the CNC, processes the feedback signal from the encoder or resolver mounted on the motor, and generates the current required to drive the motor windings to follow the programmed trajectory with precision. A drive failure causes immediate loss of control on the affected axis, rendering the machine inoperable; in multi-axis systems the CNC may raise a general alarm on all axes to protect both the machine and the workpiece in progress.

Baumüller is a German company founded in 1930 in Nuremberg, specialising in electric drive systems, servo motors, and precision industrial automation; its products are present worldwide in the machine tool, plastics, textile, and printing sectors. The BKF series belongs to a previous generation of compact digital drives, now superseded by the b maXX next-generation families: all products in this family are therefore legacy / discontinued, available only as used, NOS surplus, or through specialist repair services.

Main Technical Specifications

2-Axis Digital Position Readout (DRO) – BAUSCH & LOMB ACU-RITE IIA

The ACU-RITE IIA is a 2-axis digital position readout display (“Two-Axis Digital Readout Display”) manufactured by Bausch & Lomb under the ACU-RITE brand, documented as a position display unit for conventional machine tools (milling machines, lathes, surface grinders). The system acquires signals from optical or magnetic linear scales mounted on the machine axes and displays the position on 7-segment LED digit readouts. The unit supports display in both millimetres and inches and includes preset, incremental zero, and — in certain variants — bolt-hole circle calculator functions. The ACU-RITE Series II is available in several variants (including the IIA) differing in axis configuration and additional features.

The digital position readout is the device that allows the operator to know the precise position of the machine tool axes during manual machining. Without this unit the operator must rely solely on mechanical vernier dials and micrometers, dramatically reducing both accuracy and machining speed. A failure of the display or the acquisition circuitry makes it impossible to perform dimensionally accurate operations, increasing the risk of scrap parts and extending cycle time.

Bausch & Lomb is a historic American company founded in 1853, best known in the scientific and ophthalmic optics sector (lenses, microscopes, military telescopes). Its Scientific Instruments Division developed the ACU-RITE line of digital position readouts from the 1960s, becoming a benchmark for precision conventional machine tools. The division was divested and changed ownership several times before being acquired by Heidenhain in 1999. All products in the ACU-RITE IIA family are legacy / discontinued: available only as used, surplus, or through specialist repair services.

Main Technical Specifications

CNC Operator Panel – BOSCH PNL-CC100M

The PNL-CC100M is the operator panel (“Operator Panel” / “Bedientafel”) for the BOSCH CC100M CNC control system, designed for CNC milling machines equipped with the BOSCH CC100 series numerical control (M = milling variant). It serves as the primary human-machine interface of the CNC, integrating a monochrome display, membrane keyboard with function keys and axis keys, spindle and feed override selectors, and LED status indicators. It connects to the main CNC unit via proprietary BOSCH connectors.

The operator panel is the primary interface between the operator and the CNC numerical control: it enables ISO/G-code program entry and editing, operating mode selection (automatic, MDI, JOG, home), spindle speed and feed rate override adjustment, and real-time axis position and machine status monitoring. A failure of the operator panel makes any interaction with the CNC impossible, causing a complete machine stoppage even when all other mechanical and electrical modules are functioning normally.

BOSCH is a German multinational with a long tradition of manufacturing CNC numerical controls for machine tools (CC100, CC200, CC300, CC500, CNC 432 series). In 2001, its automation and drive activities were merged into Bosch Rexroth AG, a joint venture with Mannesmann Rexroth. All products in the CC series are legacy / discontinued: available exclusively as used/surplus or through specialist repair.

Main Technical Specifications

Industrial Power Supply – CHLORIDE ELECTRO NETWORKS P11082B

The P11082B is an industrial switching power supply (“Industrial Switching Power Supply”) manufactured by Chloride Electro Networks, designed for automation and CNC machine tool applications. The unit converts AC mains voltage into one or more regulated DC outputs required to power control boards, logic circuits, interfaces and actuators within the CNC system. The part number P11082B identifies the specific variant of this power supply within the Chloride Electro Networks product range.

The power supply is the critical component that delivers stable, regulated energy to all electronic circuits in the CNC machine: CPU boards, I/O interfaces, servo amplifiers and safety devices. A fault in the power supply causes widespread malfunctions across the entire machine, often with symptoms that are difficult to diagnose (spontaneous resets, non-repeatable CNC errors, random lockups). Timely replacement or repair is essential to restore production.

Chloride Electro Networks was a division of the British group Chloride Group plc, specialising in industrial power supplies, UPS systems and power conditioning devices for critical applications in automation, telecommunications and industry. Chloride Group was acquired by Emerson Electric in 2010; all products in this family are legacy / discontinued: available only as used, surplus or through specialist repair.

Main Technical Specifications

AC Variable Speed Drive – CONTROL TECHNIQUES UNI2403

The UNI2403 is an AC variable speed drive (“Variable Speed Drive”) from the Unidrive Classic family, manufactured by Control Techniques. Documented on CNC machining centres, milling machines and lathes equipped with three-phase induction motors, it regulates motor speed and torque via PWM modulation. It operates in open-loop V/Hz, open-loop vector (sensorless) and closed-loop vector modes with encoder feedback. The Unidrive Classic is the first generation of the Unidrive platform, predecessor to the Unidrive SP and Unidrive M families.

The variable frequency drive is the power and regulation element that converts three-phase mains voltage into variable voltage and frequency, enabling precise speed and torque control of the induction motor. A drive failure completely disables the associated axis or spindle, bringing the machine to a standstill; typical faults include overvoltage, overtemperature, loss of encoder feedback or short-circuit on the IGBT power stage.

Control Techniques is a British manufacturer founded in 1973, specialising in AC and DC drives, servo systems and industrial motors. Acquired by Emerson Electric in 1994 and subsequently by Nidec Corporation in 2012, it now operates as the Nidec Control Techniques division. The Unidrive Classic line is legacy / discontinued: available only as used, NOS or through specialist repair.

Main Technical Specifications

AC Vector Inverter / Variable Speed Drive – Control Techniques SP2402

The SP2402 is an AC variable speed drive (“AC Inverter / Variable Frequency Drive”) from the Unidrive SP series, manufactured by Control Techniques. It belongs to the Frame 2, 400 V class and is employed on CNC machine tools and industrial automation systems requiring precise speed and torque control of AC induction or permanent-magnet synchronous motors. It supports four operating modes: scalar V/Hz, Open Loop Vector (sensorless), Closed Loop Vector (with encoder), and Servo. An integrated RS485 / Modbus RTU interface and an option slot for fieldbus expansion modules (Profibus-DP, CANopen, DeviceNet, EtherCAT) are included.

The inverter converts the fixed-frequency mains supply into a variable-voltage, variable-frequency three-phase output, enabling precise control of motor speed and torque. In a CNC machining centre, a drive failure causes immediate shutdown of the controlled axis or spindle: the machine stops, the workpiece risks being scrapped, and — should active safety not intervene — a collision may occur.

Control Techniques is a British manufacturer founded in 1968 and specialised in variable-speed drives for AC and DC motors. Acquired by Emerson Electric in 1992 and later by Nidec Corporation in 2017, it now operates as Nidec Industrial Solutions. The Unidrive SP series is legacy / discontinued: the platform has been superseded by the Unidrive M family; SP drives are available exclusively as used, NOS (surplus), or through specialist repair centres.

Main Technical Specifications

AC Variable Speed Drive – CONTROL TECHNIQUES SP1404

The SP1404 is an electronic AC variable speed drive (“AC Variable Speed Drive / Inverter”) by Control Techniques, part of the Unidrive SP series. Designed for control of three-phase induction motors and permanent magnet motors, it supports open-loop vector (RFC-A), closed-loop vector with encoder feedback, and servo control modes. Nominal input voltage 380–480 V AC three-phase 50/60 Hz; nominal output current approximately 14 A continuous; power class 5.5–7.5 kW at 400 V. Features an onboard PLC, digital and analogue I/O, RS485 serial interface, and expansion slots for optional fieldbus modules.

The AC variable speed drive is the power electronic converter that transforms fixed-frequency mains supply into variable voltage and frequency to regulate motor speed and torque. In CNC machine tools it controls the spindle, feed axes, or auxiliary motors, ensuring precise and continuous regulation across the full operating range. A drive failure results in the immediate loss of control of the affected axis or spindle, halting the machine and preventing resumption of machining.

Control Techniques is a British manufacturer of variable speed drives and servo systems, founded in 1973 and headquartered in Newtown, Wales. Acquired by Emerson Electric in 1992 and subsequently by Nidec Corporation in 2017, it now operates as Nidec Control Techniques. The Unidrive SP series is legacy / discontinued in its original variants, progressively replaced by the Unidrive M series: spare units are available primarily as used stock, NOS surplus, or through specialist repair services.

Main Technical Specifications

Digitax Servo Drive – Control Techniques DBE 420

The DBE 420 is an AC digital servo drive (“Digitax AC Digital Servo Drive”) manufactured by Control Techniques, part of the DIGITAX family for controlling AC brushless servo motors in motion control and CNC machine tool applications. The unit operates as a closed-loop digital servo amplifier, regulating speed, torque and position while interfacing with the CNC controller via fieldbus and encoder feedback. The designation DBE 420 identifies the size and variant within the DIGITAX catalogue; the product may exist in multiple hardware and firmware revisions.

The DIGITAX DBE 420 servo drive is the electronic controller that closes the current, speed and position loops on the servo axis: it interprets the CNC references in real time and compensates for load disturbances, maintaining axis precision and dynamics throughout machining. A drive failure renders the controlled axis completely inoperative, halting production; loss of closed-loop control can result in mechanical collisions or dimensional rejects in the workpiece.

Control Techniques is a British manufacturer and world leader in variable-speed drives and servo systems, founded in 1973 in Newtown (Wales, UK). Acquired by Emerson Electric in 1990 and subsequently by Nidec Corporation in 2017, it produces the Unidrive, Commander and DIGITAX servo drive families. Products in the DIGITAX DBE series are legacy / discontinued: available exclusively as used stock, NOS surplus, or through specialist repair services.

Main Technical Specifications

DC Motor Drive – Control Techniques DB 420 NP

The DB 420 NP is a DC motor drive (“DC Motor Drive”) manufactured by Control Techniques, belonging to the DB series of the Welsh manufacturer’s industrial drive range. The part number identifies a combined control and power unit for DC motors intended for industrial motion control applications; the NP designation denotes a specific constructional variant (typically “Non-Plug-in” or a configuration without a removable optional module). The drive manages the speed and torque regulation loops, interfacing with the CNC system’s control bus and with the motor’s tachogenerator or encoder feedback. The product is documented on CNC machine tools, automated production lines and numerical control systems using DC motors for axis or spindle drives.

The DC drive is the core of the motor control system: it receives the speed or torque reference from the numerical controller, regulates voltage and current to the motor armature and closes the feedback loop to deliver the required motion profile with precision and stability. A drive failure renders the controlled motor completely unmanageable, causing immediate process stoppage and a real risk of mechanical damage to moving parts; availability of a replacement unit is therefore critical to limiting unplanned machine downtime.

Control Techniques, founded in 1961 in Newtown (Wales, UK), is one of the world’s leading manufacturers of variable-speed drives for AC and DC motors, servo drives and motion control systems (Mentor, Unidrive, Commander, Digitax, Epsilon families). Acquired by Emerson Electric in 1992 and subsequently by Nidec Corporation in 2017, it continues to operate as an independent brand within the group. Products in the DB series are legacy / discontinued: available only as used, surplus or through specialist repair.

Main Technical Specifications

Unidrive AC Variable Speed Drive – Control Techniques UNI1401

The UNI1401 is an AC variable speed drive (“AC Variable Speed Drive”) from the Unidrive Classic series by Control Techniques. Designed to control three-phase asynchronous motors, the drive supports both open-loop (V/f) and closed-loop field-oriented control (flux vector), with a three-phase 380–480 V AC input and a rated power of approximately 1.5 kW. The unit supports encoder feedback for high-precision speed and torque applications.

The Unidrive drive controls the speed and torque of the AC motor by modulating the output voltage and frequency using PWM technique: it provides smooth starts, controlled regenerative braking, and speed stability under varying loads. In case of failure, the driven axis or spindle loses complete control, rendering the machine inoperable until the drive is replaced or repaired.

Control Techniques is a British manufacturer founded in 1968, specialised in variable speed drives and servo drives for industrial automation. Acquired by Emerson Electric in 1994 and later by Nidec Corporation in 2017, it now operates as Nidec Industrial Solutions. The Unidrive Classic series is legacy / discontinued, superseded by the Unidrive SP and Unidrive M generations.

Main Technical Specifications

Variable Speed Drive – Control Techniques SP1403

The SP1403 is a variable speed drive (“Variable Speed Drive / Servo Drive”) from the Unidrive SP family manufactured by Control Techniques, documented in service on CNC machine tools, machining centres and industrial automation systems requiring precise control of asynchronous or synchronous motors. The Unidrive SP (“Universal Drive”) family supports open-loop, RFC (Rotor Flux Control) and servo modes with encoder feedback, managing the complete speed/torque regulation chain from the DC-bus rectifier stage through the IGBT inverter output. The unit integrates short-circuit, over-temperature and overvoltage protection, and is expandable with optional fieldbus communication and advanced encoder input cards.

The drive is the device that converts mains electrical energy into a variable voltage and frequency suitable for the motor, enabling precise speed and torque control throughout all machining phases. On a CNC machining centre its failure stops the spindle or the controlled axis, rendering the machine completely unusable; recovery requires replacing the drive and reconfiguring the regulation parameters (gains, ramps, current limits) to restore the machine’s original performance.

Control Techniques, founded in 1968 in Wales (UK), is one of the world’s leading manufacturers of variable speed drives for AC and DC motors; the Unidrive range has become a benchmark in global manufacturing industry. Acquired by Emerson Electric and subsequently by Nidec Corporation in 2017, products are now marketed under the Nidec | Control Techniques brand. The Unidrive SP series has been superseded by the Unidrive M series and is considered legacy / discontinued: available primarily as used, surplus or through specialist repair.

Main Technical Specifications

AC Variable Speed Drive – CONTROL TECHNIQUES SP1401

The SP1401 is an AC variable speed drive (“AC Variable Speed Drive” / inverter) manufactured by Control Techniques, belonging to the Commander SP family. Designed for three-phase induction motor speed control, it is used in CNC machine tools, material handling systems, and industrial automation. The unit integrates V/f and sensorless vector control logic, electronic protections (over-temperature, over-current, under-voltage), and a serial communication interface. Since the alternative code matches the main part number, the component is uniquely identified as SP1401.

The SP1401 drive converts mains voltage into variable voltage and frequency via PWM modulation, enabling precise motor speed control according to the CNC reference. It is the component that makes continuous feed rate or spindle speed regulation possible: without it the motor would operate only at fixed mains frequency, making any controlled machining impossible. A drive failure causes immediate stoppage of the affected axis or spindle, resulting in machine downtime.

Control Techniques is a British manufacturer founded in 1973, a world leader in variable speed drives and servo drives (product ranges: Unidrive, Commander, Mentor, Digitax). Acquired by Emerson Electric in 2004 and subsequently by Nidec Corporation in 2017, it now operates under the Nidec brand. The Commander SP range is legacy / discontinued: available only as used, surplus, or through specialist repair services.

Main Technical Specifications

Axis Servo Drive – CONTROL TECHNIQUES MAXAX 200/3000

The MAXAX 200/3000 is an axis servo drive (“Axis Servo Drive”) manufactured by Control Techniques, belonging to the MAXAX family, a series dedicated to axis control in motion control applications for CNC machine tools. The part number identifies a compact module designed to drive servo motors (brushless AC or DC) for positioning and machining axes, with the rated voltage class and nominal speed encoded in the product designation. The module manages the current and velocity loops of the axis, interfacing with the CNC controller via an analogue speed reference and encoder feedback signals. Multiple hardware revisions and configuration variants may exist.

The axis servo drive is the power regulator that converts the position or speed references issued by the CNC into precise control currents for the axis motor: it ensures high dynamic response, positional stiffness and motor protection during machining operations. If it fails, the affected axis becomes uncontrollable or is locked in a safe state, rendering the machine completely unusable and halting production.

Control Techniques is a British manufacturer founded in 1973 in Newtown, Wales, specialising in high-performance AC, DC and servo drives for industrial automation; in 1992 it was acquired by Emerson Electric and subsequently, in 2017, by Nidec Corporation, now operating under the brand Nidec Control Techniques. All products in the MAXAX family are legacy / discontinued: available only as used, surplus or through specialist repair services.

Main Technical Specifications

Servo Axis Drive – CONTROL TECHNIQUES MAXAX 100/3000

The MAXAX 100/3000 is a servo axis drive (“Servo Axis Drive”) manufactured by Control Techniques, belonging to the MAXAX family of the MAX multi-axis control platform. The designation MAXAX identifies the module as an axis drive (AX = axis) integrated into the MAX system; the model parameters indicate a peak current class of 100 A and a nominal motor speed of 3000 rpm. The module interfaces with the central MAX controller and the axis servo motor, managing the position–velocity–current control chain. Hardware revisions and firmware variants may exist; always verify compatibility with the installed controller version.

The servo axis drive is the component that translates position and velocity commands from the CNC into precise current signals to the motor, closing the regulation loops and ensuring exact axis positioning during machining. A failure in this module makes the axis completely uncontrollable: the machine triggers an alarm and production stops immediately, with a real risk of collisions or dimensional rejects across the entire batch being machined.

Control Techniques is a British manufacturer of variable speed drives and servo systems, founded in Newtown, Wales (UK), and established as a global reference in industrial motion control. Acquired by Emerson Electric in 2004 and subsequently by Nidec Corporation (Japan) in 2017, it now operates as a strategic brand within the Nidec Motion Control division. Products in the MAXAX series are legacy / discontinued: available only as used, surplus or through specialist repair.

Main Technical Specifications

Digital Brushless Servo Drive – Control Techniques DBE 220

The DBE 220 is a digital brushless servo drive (“Digital Brushless Servo Drive”) manufactured by Control Techniques, belonging to the family of digital drives for brushless AC/DC servo motors used in CNC machine tools and industrial automation systems. The unit manages the current, speed and position control loops of the servo motor, receiving a digital or analogue reference from the CNC controller and driving the motor using high-frequency digital PWM modulation. Variants with different nominal current and supply voltage may exist; always verify the nameplate data before any replacement.

The digital servo drive is the core of the axis motion system: it converts the CNC’s numerical commands into precise power currents that accelerate, hold and decelerate the servo motor with the dynamic response demanded by the machining process. Without this component the controlled axis is stationary or uncontrollable; a failure causes an immediate machine stop with a drive alarm, making any machining cycle impossible.

Control Techniques is a British manufacturer founded in 1968 in Newtown (Wales), a pioneer in the development of AC inverters and digital servo drives for the global manufacturing industry. Acquired by Emerson Electric in 2004 and subsequently integrated into the Nidec Corporation group in 2017, the company continues to manufacture drives for industrial automation. Products from the older series, including the DBE family, are legacy / discontinued: available exclusively as used, NOS, or through specialist repair services.

Main Technical Specifications

Digital Servo Drive for Brushless Motor – CONTROL TECHNIQUES DB420

The DB420 is a digital servo drive (“Digital Servo Drive”) belonging to the DIGITAX series by Control Techniques, designed for speed, position and torque control of brushless AC motors (permanent-magnet AC synchronous servomotors). It is documented as a component in CNC axis-control systems for machining centres, transfer machines and high-precision industrial automation. The DB420 receives the reference from the CNC controller and drives the servo motor via a high-switching-frequency three-phase PWM output; it internally manages the current (torque) and speed loops, with feedback from an incremental encoder or resolver. The “DB” designation identifies the brushless family within the DIGITAX series; “420” refers to the current/voltage rating. No distinct alternative part number is known other than the main code.

The digital servo drive is the electronic controller that translates CNC commands into precise current delivered to the axis motor: it maintains position and speed with sub-millisecond accuracy, ensuring dimensional repeatability of the machined workpiece. If the DB420 fails, the controlled axis is completely locked or uncontrollable; the machine triggers an alarm and cannot produce, with immediate impact on productivity and a potential risk of collision.

Control Techniques is a British manufacturer founded in the 1970s, a world leader in the design of AC drives, servo drives and motion control systems. The company was acquired by Emerson Electric in 2004 and subsequently by Nidec Corporation in 2017, continuing to operate under its own brand. The original generations of the DIGITAX product line (prior to the ST series) are legacy / discontinued: available exclusively as used, surplus or through specialist repair.

Main Technical Specifications

AC Variable Speed Drive – Control Techniques UNI3401

The UNI3401 is an AC variable speed drive from the Unidrive Classic series by Control Techniques. It is a medium-frame (frame 3) three-phase inverter for 400 V AC supply, designed to control induction and permanent-magnet synchronous motors in CNC machine tools, industrial automation, and motion control applications. The drive supports five operating modes: open-loop V/Hz, open-loop vector, closed-loop vector (with encoder feedback), servo (brushless PM motors), and regenerative. It is not a CPU board or standalone I/O module, but a fully integrated power conversion and digital regulation drive. Option expansion slots are provided for additional I/O, fieldbus modules, and supplementary encoder interfaces.

The Unidrive drive is the core of the axis and spindle motion system in a CNC machine: it receives the speed or torque reference from the numerical control and continuously adjusts output frequency and voltage to drive the motor with high accuracy. A drive failure immediately stops the controlled axis or spindle, rendering the machine unusable; replacing or repairing the drive becomes the critical path to restoring production.

Control Techniques is a British manufacturer of drives and servo systems founded in 1968 in Newtown (Wales, UK), acquired by Emerson Electric in 1994 and absorbed into the Nidec Corporation group in 2017. The Unidrive Classic series is legacy / discontinued: superseded by the Unidrive SP series and subsequently by Unidrive M, it is now available only as used, surplus, or through specialist repair centres.

Main Technical Specifications

DC Switching Power Supply – COSEL LDC15F-2

The LDC15F-2 is a DC switching power supply (“DC Switching Power Supply”) manufactured by COSEL, belonging to the LDC series of compact low-power industrial converters. Documented as a logic supply component in CNC control systems and industrial panels, it delivers a regulated DC output voltage — in the F2 variant typically +12 V DC — with a nominal output power of approximately 15 W. The unit accepts wide-range universal AC input and includes built-in overload and short-circuit protection.

The LDC15F-2 power supply provides stable, filtered logic supply voltages to the machine’s CNC control circuits: CPU boards, I/O modules, encoders, and communication interfaces all depend on clean, stable voltage to operate correctly. A failure or excessive ripple causes random CNC errors, parameter loss, unexpected shutdowns, or irreversible damage to control boards.

COSEL Co., Ltd. is a Japanese manufacturer founded in 1969, headquartered in Toyama, specialising in high-reliability switching power supplies for industrial, medical, and CNC applications. COSEL products are globally recognised for their long operational life and low electromagnetic interference. Some legacy series such as the LDC are legacy / discontinued: available primarily as NOS (new old stock), used, or through specialist repair.

Main Technical Specifications

DIN Rail Switching Power Supply 75 W / 18 V – COSEL LDA75F-18

The LDA75F-18 is an industrial DIN rail switching power supply (“DIN Rail Switching Power Supply”) manufactured by COSEL, belonging to the LDA75F series rated at 75 W. The unit accepts universal AC (85–264 V AC, 47–63 Hz) or DC (120–370 V DC) input and delivers a regulated 18 V DC output at a nominal maximum current of approximately 4.2 A. Cooling is achieved by natural convection, with no fan required. Isolation is reinforced type in compliance with major international standards (UL, CE). No official hardware revisions have been publicly documented.

The switching power supply converts mains AC voltage into a stable, regulated DC voltage, essential for powering CNC control logic boards, I/O modules, sensors, transducers and all low-voltage devices on the machine tool. A power supply failure causes an immediate loss of auxiliary power: the CNC triggers an alarm, drives may lose their enable logic voltage, and the machine stops in an uncontrolled manner, risking workpiece loss and tool damage.

COSEL Co., Ltd. is a Japanese manufacturer founded in 1969, specialised in the design and production of high-reliability AC/DC switching power supplies for industrial, medical and telecommunications applications. The LDA series is the compact DIN rail range of reference for industrial control panels, renowned for low output ripple, high efficiency and long operating life. The LDA75F-18 model is legacy / discontinued: available exclusively as NOS stock, used units, or through specialist distributors.

Main Technical Specifications

150W 12V DC Switching Power Supply – COSEL LDA150W-12

The LDA150W-12 is a single-output 12 V DC / 12.5 A industrial switching power supply (“Switching Power Supply”) manufactured by COSEL, belonging to the LDA150W series. The part number encodes the nominal output power of 150 W and the regulated output voltage of 12 V DC. The input is universal AC (85–264 V AC, 47–63 Hz), compatible with both 110 V and 230 V mains without manual range switching. The unit is designed for panel or DIN-rail mounting inside electrical cabinets and is widely used as an auxiliary power supply in CNC control systems from various manufacturers (Fanuc, Mitsubishi Electric, Mazak, Okuma, and others). The alternative commercial part number is listed exclusively in the technical table below.

The auxiliary power supply converts mains voltage into stable DC voltage, which is essential to power the CNC’s control logic, I/O modules, encoders, position sensors, operator panel, and safety circuits. A failure or output voltage drift produces erratic machine behaviour or shutdowns that are particularly difficult to diagnose, since symptoms typically appear intermittently — position errors, unexpected resets, random alarms — before the unit fails completely.

COSEL Co., Ltd. is a Japanese switching power supply manufacturer founded in 1969 and headquartered in Toyama, Japan, specialised in high-reliability power solutions for industrial, medical, and telecommunications applications. COSEL products are internationally recognised for their high build quality, long service life, and compliance with major international certifications (UL, CE, TÜV). The company remains active and independent; however, certain older revisions or series may be legacy / discontinued — it is advisable to verify availability of the specific part number with an authorised distributor before ordering.

Main Technical Specifications

Heavy Duty Electric Motor – DAEWOO DSRT15XA50

The DSRT15XA50 is a heavy-duty electric motor for CNC machine tools (“Heavy Duty Electric Motor”) manufactured by DAEWOO Heavy Industries, used in DAEWOO HEAVY range machine tools (vertical and horizontal machining centres, CNC lathes and large-format milling machines). The part number DSRT15XA50 identifies a specific power, voltage and flange configuration within the DAEWOO heavy-duty motor family. Depending on the host machine, the component may serve as a feed axis motor or spindle motor; position and speed feedback is typically provided by an integrated encoder or resolver.

The DSRT15XA50 motor is the electromechanical component that converts electrical power into mechanical torque to drive the CNC machine’s feed axes or spindle. It plays a critical role in the motion control system: it ensures precise, repeatable axis positioning or steady spindle rotation in response to numerical control commands. Failure of this motor causes immediate machine downtime; no machining is possible until the component is replaced or repaired, with a direct impact on production output.

DAEWOO Heavy Industries was one of South Korea’s leading industrial conglomerates, with a machine tool division (DAEWOO Machine Tool Co.) producing CNC lathes, machining centres and high-end milling machines widely used in the automotive and aerospace sectors. Following the DAEWOO group’s restructuring, the division was absorbed into Doosan Infracore (now HD Hyundai Infracore), which continued production under the new brand. Original DAEWOO Heavy components are legacy / discontinued: available exclusively as used, surplus stock or through specialist repair.

Main Technical Specifications

Hydraulic Pump Control Unit – DAIKIN DHA00900

The DHA00900 is an electronic hydraulic pump control unit (“Hydraulic Pump Control Unit”) manufactured by DAIKIN Industries, industrial hydraulics division. This module forms the logical core of the hydraulic power unit fitted on CNC machine tools, machining centres and industrial systems that use DAIKIN hydraulic components for workpiece clamping, axis counterbalancing, automatic tool change and other hydraulic actuators. The unit integrates pump motor start/stop logic, operating pressure regulation, fault supervision (overtemperature, low oil, pressure anomaly) and the signal interface toward the CNC controller. No publicly documented variants or revisions are known; part number DHA00900 unambiguously identifies the component.

The control unit governs the entire hydraulic pump assembly: it starts the electric motor, brings the circuit up to operating pressure and continuously monitors oil level, temperature and pressure circuit integrity. In the event of a failure, the machine immediately loses its ability to generate the hydraulic pressure required for workpiece clamping, automatic tool change and vertical axis counterbalancing — the outcome is an immediate machine stop, with a concrete risk of losing the part being machined or causing mechanical damage to unbalanced axes.

DAIKIN Industries is a Japanese multinational founded in 1924, best known as a world leader in air conditioning and industrial ventilation. Its hydraulic division — DAIKIN Hydraulics — manufactures axial piston pumps, vane pumps, power units and electronic controls for industrial and machine tool applications, distributed worldwide with specialist technical support. Electronic modules of this generation are to be considered legacy / discontinued: availability is limited to the used market, industrial surplus stock and specialist repair services.

Main Technical Specifications

Axis Servo Drive – DOOSAN DVSD-TT-14A-05

The DVSD-TT-14A-05 is a digital CNC axis servo drive (“Digital Axis Servo Drive”) manufactured by DOOSAN, a component of the proprietary VISION CNC system installed on machining centres and CNC lathes in the DOOSAN/Daewoo range. The part number identifies a DVSD-series drive with TT-type power stage, 14 A rated current and variant 05. It manages the current and velocity control loops of the servo motor on a linear or rotary axis, interfacing with the VISION control CPU via the internal digital bus. No standard accessories are known to be included.

The servo drive is the electronic node that closes the current and velocity loop on the axis motor: it receives the position/speed reference from the CNC CPU and drives the servo motor with microsecond precision, ensuring dimensional accuracy and repeatability throughout machining. A drive failure immediately stops the affected axis with a CNC alarm: the machine cannot operate until the component is replaced or repaired, resulting in unplanned production downtime.

DOOSAN is a South Korean industrial conglomerate whose machine tool division was consolidated through the acquisition of Daewoo Heavy Industries in 2005; it produces CNC lathes, vertical and horizontal machining centres, and proprietary control systems distributed worldwide. Products in the VISION series are legacy generation: legacy / discontinued, available primarily as used, surplus or through specialist repair.

Main Technical Specifications

Optical Incremental Encoder – DYNAMIC RESEARCH CORP C25-81B15-2500AG00

The C25-81B15-2500AG00 is an optical incremental encoder (“Optical Incremental Encoder”) manufactured by Dynamic Research Corp, designed as a position and velocity transducer for CNC systems and numerically controlled machine tools. The part number identifies a C25-series encoder with a resolution of 2500 pulses per revolution (PPR), type-A output and standard configuration (suffix G00). It provides quadrature signals A, B and zero-pulse Z, compatible with RS-422 / TTL differential interfaces for high immunity to electromagnetic interference typical of industrial environments.

The rotary encoder is the feedback transducer that informs the CNC of the actual position and speed of an axis or spindle: without it the numerical controller cannot close the position loop and the machine is inoperable. A faulty or degraded-signal encoder causes positioning errors, feedback alarms and — in the worst cases — uncontrolled axis motion with collision risk.

Dynamic Research Corp (DRC) was a US manufacturer specialising in optical incremental encoders for motion control and CNC applications, active primarily during the 1980s and 1990s. All products in this line are legacy / discontinued: available only as used spares, NOS (new old stock) or through specialist repair services.

Main Technical Specifications

Incremental Optical Encoder – DYNAMICS RESEARCH CORP 25-S031-B15-1800G0C0

The 25-S031-B15-1800G0C0 is an incremental optical encoder manufactured by Dynamics Research Corp (DRC), with a resolution of 1800 lines/rev (CPR). The manufacturer part number identifies an encoder from the S031 series, flange/mounting configuration B15, and differential output configuration G0C0. The component is documented on a variety of CNC machine tools that use encoder feedback for linear axes or spindle. Other resolution and output variants exist within the same product family; this listing refers specifically to the 1800 CPR version.

The encoder is the position and velocity transducer that feeds the CNC controller with the feedback signal: it converts the mechanical rotation of the motor shaft into high-precision electrical pulses, enabling the position loop to correct axis trajectory or spindle speed in real time. Without the encoder signal the CNC is blind: the axis triggers a following error alarm or the spindle loses speed control, making any machining operation impossible.

Dynamics Research Corp (DRC) was a prominent US manufacturer (Wilmington, MA) specialising in precision optical encoders for machine tools, robotics, and industrial automation. The company was acquired by Danaher Corporation, and its encoder product lines were absorbed into the Dynapar brand. All original DRC series products are legacy / discontinued: supply relies entirely on used stock, surplus, or specialist repair services.

Main Technical Specifications

Switching Power Supply – EFORE SR 92A530

The SR 92A530 is an industrial switching power supply (“Switching Power Supply”) manufactured by EFORE, documented as a component of ABB Robotics industrial robot control cabinets. The unit supplies regulated DC voltages to the robot controller’s electronic boards, ensuring stable power for CPU cards, I/O modules, and servo drives. The part number SR 92A530 identifies this unit within the EFORE OEM power supply family for ABB; later hardware revisions with minor circuit variants may exist.

The power supply is the energy core of the robot control cabinet: it converts mains AC voltage into stabilised and filtered DC voltages, essential for the reliable operation of all onboard electronics. A failure of this unit causes immediate robot shutdown — no axis moves, the system loses its state variables and the production line stops. The quality of the output voltages directly affects the stability of the servo drives and the service life of the downstream electronic boards.

EFORE is a Finnish manufacturer of industrial switching power supplies, specialised in OEM supply for critical sectors including robotics, industrial automation, telecommunications and medical equipment. The company has operated as a long-standing strategic power supply vendor for ABB Robotics control systems. Products in the SR series for previous-generation ABB controllers are considered legacy / discontinued: available only as used, surplus or through specialist repair.

Main Technical Specifications

Servo Axis Drive – EL.GE AZMLM2B

The AZMLM2B is an electronic servo axis drive (“Servo Axis Drive”) manufactured by EL.GE (Elettronica Generale), an Italian company specialising in electronic control systems for CNC machine tools. The module belongs to the EL.GE modular drive family for brushless or DC servo motor control in precision machining applications. The part number AZMLM2B uniquely identifies the version and current rating within the manufacturer’s product range. The drive may be available in different current or voltage variants depending on the machine configuration; no distinct official alternative part number separate from the primary code is known.

The servo axis drive is the electronic module that regulates the torque, speed, and position of the servo motor connected to the controlled axis: it receives setpoints from the CNC or interpolator and closes the current, speed, and position loops in real time. In the event of a failure, the affected CNC axis becomes uncontrollable, the machine triggers an alarm, and production halts immediately; on multi-axis machines a single faulty drive can stop the entire machining cycle, resulting in potentially significant downtime costs.

EL.GE (Elettronica Generale) is an Italian company with decades of experience in designing and manufacturing electronic systems for machine tools, including servo and spindle drives, power supplies, and CNC control boards. Its products equip various Italian manufacturers of machining centres, CNC lathes, and milling machines. A significant part of the historical product range is to be considered legacy / discontinued: available mainly as used, reconditioned, or through specialist repair services.

Main Technical Specifications

24 V DC Switching Power Supply – ELCO K100A-24

The K100A-24 is a 24 V DC switching power supply (“DC Switching Power Supply”) manufactured by ELCO, designed to power control electronics in industrial environments and on CNC machine tools. The -24 suffix identifies the nominal regulated output voltage of 24 V DC. The unit is intended for powering I/O modules, PLCs, safety relays, encoders and electrohydraulic valves located in the machine’s electrical cabinet. Multiple hardware variants may exist; verify the revision before replacement.

The DC power supply is the heart of the logic power distribution in a CNC machine: it converts the mains voltage to stable, filtered 24 V DC, ensuring continuous supply to PLCs, I/O modules, encoders, safety relays and low-power actuators. Its failure causes immediate shutdown of all control circuits, resulting in total machine downtime; an unstable or out-of-tolerance output voltage can also generate communication errors, unexpected CNC resets and anomalous axis behaviour.

ELCO is a manufacturer specialising in industrial power supplies and power electronics components for industrial automation and machine tools. Products in the K100A series are engineered for demanding industrial environments, with particular attention to reliability under variable loads and mains disturbances. Models in this family are legacy / discontinued: available exclusively as used, surplus or through specialist repair services.

Main Technical Specifications

12” Monochromatic CRT Monitor – EVERSONIC DISPLAY 2000 TK12M165HER2

The TK12M165HER2 is a 12” monochromatic industrial CRT monitor (“12-inch Monochromatic Industrial CRT Monitor”) belonging to the DISPLAY 2000 series by EVERSONIC, a Taiwanese manufacturer specialising in displays for industrial automation and CNC machine tools. The monitor is designed to serve as the operator’s visual interface on CNC systems from various manufacturers and generations, with video inputs compatible with TTL or industry-standard composite signals. The part number TK12M165HER2 identifies the specific variant featuring a monochromatic phosphor tube (typically green or amber) with a 12” diagonal. The unit does not include its own data-processing capability: it is a passive display dedicated to showing machine parameters and status.

The CNC monitor is the display panel that allows the operator to read machine status, running programmes, alarms, and machining parameters in real time. Its absence or a CRT tube failure makes any setting, programming, or control operation impossible: the machine is effectively inoperable until the unit is replaced.

EVERSONIC Technology Co., Ltd. is a Taiwanese manufacturer active in the industrial and professional monitor sector, specialising in displays for CNC, medical, and automation applications. Monitors in the DISPLAY 2000 series, based on monochromatic CRT technology, are legacy / discontinued: CRT tube production has ceased worldwide and these components are available exclusively as used, NOS (new old stock), or through specialist repair.

Main Technical Specifications

14″ Colour CNC Monitor – FANUC A61L-0001-0096

The A61L-0001-0096 is a 14″ colour CRT monitor (“14-inch Colour CRT Monitor”) manufactured by FANUC, documented as a display component for FANUC CNC Series 0, 15, 16, 18 and 21 systems installed on machining centres, CNC lathes and milling machines. The monitor handles the display of the operator interface: part programs, machine parameters, alarm messages and system diagnostics. Display technology is CRT (Cathode Ray Tube) colour; the video signal is supplied directly from the CNC unit via a dedicated connection. Variants may exist with different internal revisions of the deflection circuit or connector configurations.

The operator monitor is the primary visual interface of the CNC system: it displays in real time the machining programs, machine parameters, active alarms and axis status. Without a working monitor the operator cannot program, modify parameters, read alarms or carry out any diagnostic operation, making the machine completely inoperable regardless of the condition of all other components.

FANUC (Fuji Automatic NUmerical Control) is the world’s leading manufacturer of CNC systems, servo motors, industrial robots and factory automation, founded in Japan in 1956. The A61L series monitors belong to a generation of CNC peripherals now legacy / discontinued, replaced in modern installations by LCD flat panel displays; availability is limited to the used market and specialist repair services.

Main Technical Specifications

14-Inch Colour CRT Monitor – FANUC A61L-0001-0094

The A61L-0001-0094 is a 14″ colour CRT monitor (“14-inch Colour CRT Monitor”) manufactured by FANUC, designed for use with FANUC Series 0, 15, 16, 18 and 21 CNC control systems. The cathode ray tube display provides graphic and text rendering for the operator interface (HMI) on CNC control panels. The unit supports analogue RGB video with composite sync or separate H/V sync signals and is available in variants for 100–120 V and 200–240 V AC, 50/60 Hz supply.

The monitor is the central visual component of the CNC operator panel: without it, the operator cannot view machine status, part programs, alarms or machining parameters. A monitor failure effectively stops the machine because the HMI becomes completely inaccessible, preventing any production cycle from being started or managed.

FANUC (Fuji Automatic NUmerical Control) is the world’s leading manufacturer of CNC systems, industrial robots and factory automation, founded in Japan in 1956 by Seiuemon Inaba as a division of Fujitsu and independent since 1972. CRT monitors in the A61L series are legacy / discontinued: LCD drop-in retrofit units are now the most widely adopted replacement solution in the industrial spare-parts market.

Main Technical Specifications

9″ Monochrome CRT Monitor – FANUC A61L-0001-0093

The A61L-0001-0093 is a 9″ monochrome CRT monitor (“9-inch Monochrome CRT Display”) manufactured by FANUC, used as the standard operator display unit in FANUC CNC Series 0, Series 6, Series 10/11/12 and Series 15 control systems. The monochrome phosphor cathode ray tube display (typically green P31 or amber P39) renders the CNC operator interface: active programs, machine status, alarm messages and axis coordinates. It connects to the control unit via the dedicated video board housed in the FANUC cabinet. It carries no independent CNC logic and is a pure display peripheral.

The CRT monitor is the primary operator interface of the numerical control: without it the operator cannot view the running program, read alarm messages, check axis coordinates or interact with the CNC through the keypad. A failed monitor renders the machine operationally unusable, blocking all production, diagnostic and setup activities and causing an immediate production stoppage.

FANUC is the world leader in CNC systems, industrial robots and factory automation, founded in Japan in 1956 as a Fujitsu division and independent since 1972. This monitor belongs to the classic display line for CNC systems of the 1980s–1990s and is legacy / discontinued: available only as used, surplus stock or through specialist CRT repair services and LCD retrofit kits.

Main Technical Specifications

14″ Colour CRT Monitor – FANUC A61L-0001-0074

The A61L-0001-0074 is a 14″ colour cathode-ray tube (CRT) monitor (“14″ Colour CRT Monitor”) manufactured by FANUC, used as the integrated display unit in MDI/CRT operator consoles of FANUC Series 0, Series 6, Series 10/11/12, Series 15 and Series 16/18/21 CNC systems, as well as selected FANUC robot cells of the same era. The unit receives the video signal from the control unit via dedicated cabling and a proprietary connector, rendering all CNC operator screens in colour CRT technology. No distinct hardware revisions with separate part numbers are documented; production batches may differ only in minor internal components.

The monitor is the primary visual interface between the operator and the CNC system: without it, it is impossible to view part programmes, machine parameters, diagnostics, or alarm messages. A monitor fault effectively halts machine operation even when the control electronics are fully intact, making it impossible to interact with menus, reset alarms, or modify critical parameters.

FANUC (Fuji Automatic NUmerical Control) is the world’s leading manufacturer of CNC systems and industrial robotics, headquartered in Oshino, Yamanashi, Japan. Founded in 1956 as a division of Fujitsu and independent since 1972, FANUC holds the highest global market share in the CNC sector. CRT monitors of the A61L family are legacy / discontinued: CRT technology is no longer manufactured industrially and these components are available exclusively as used, surplus, or via replacement with compatible LCD retrofit kits.

Main Technical Specifications

Servo Axis Drive – FERROCONTROL S04-00-19

The S04-00-19 is a servo axis drive module (“Servo Axis Drive”) manufactured by FERROCONTROL, designed for use in FERROCONTROL E°CNC systems fitted to CNC machining centres for wood, panel, glass and stone processing. The module controls servo-driven axes by managing the current and velocity loops of the connected servo motor. The full part reference is S04-00-19 (internal code S040019).

The servo axis drive is the heart of the machine’s positioning system: it converts the CNC controller’s position and velocity commands into motor drive currents, closing the feedback loop via encoder or resolver. A drive failure immediately halts the affected axis, making any machining operation impossible until the module is replaced or repaired.

FERROCONTROL Steuerungssysteme GmbH & Co. KG is a German manufacturer based in Herford, specialising in CNC systems for the wood and panel processing industry. Its E°CNC systems are fitted to machines from many leading sector OEMs including Holzma, Weeke and Brandt. FERROCONTROL is part of the HOMAG Group. Spares for older systems are legacy / discontinued and available only through specialist channels or repair services.

Main Technical Specifications

Spindle Inverter Drive 3.7 kW – Fuji Electric FRN3. 7M5-2

The FRN3. 7M5-2 is a 3.7 kW CNC spindle inverter drive (“Spindle Inverter Drive”) from the FRENIC 5000MS5 series, manufactured by Fuji Electric. Designed specifically for variable-speed spindle control in CNC machine tools (vertical and horizontal machining centres, CNC lathes, milling machines), the drive converts three-phase mains voltage into variable-frequency, variable-voltage output to control spindle motor speed and torque. It incorporates features dedicated to machine tool requirements: spindle orientation for automatic tool change, C-axis mode, and DC braking. Available in multiple power ratings within the same MS5 family.

The FRENIC 5000MS5 spindle inverter drive is the electronic unit that converts three-phase mains power into variable frequency and voltage to govern spindle motor speed and torque throughout every phase of the machining cycle. It manages critical functions including spindle orientation for automatic tool changers, closed-loop control via encoder feedback, and rapid braking on stop. A failure of this unit renders the spindle completely uncontrollable, halting production and requiring immediate specialist intervention.

Fuji Electric Co., Ltd. is a Japanese industrial group founded in 1923 and one of the world’s leading manufacturers of industrial inverters, electric drives and automation systems. The FRENIC 5000MS5 series was dedicated specifically to the CNC machine tool industry and is today legacy / discontinued, superseded by newer lines such as FRENIC-Ace and FRENIC-MEGA; spares are available only as used units, surplus stock or through specialist repair services.

Main Technical Specifications

Variable Frequency Drive (Inverter) – FUJI FRN003M3-21

The FRN003M3-21 is a variable frequency drive / inverter (“Variable Frequency Drive” – VFD) belonging to the FRENIC family manufactured by FUJI Electric. The part number identifies a compact frequency converter in the ~0.3–0.4 kW power class, 200 V class, designed for the speed control of three-phase induction motors in industrial applications and CNC machine tools. The unit belongs to one of the historical compact FRENIC series produced by FUJI Electric from the 1990s onward for motion control applications across a wide range of manufacturing sectors.

The frequency inverter converts fixed-frequency mains power into a variable-frequency, variable-amplitude three-phase output, enabling continuous and precise speed regulation of the driven induction motor. In a CNC machine tool it can serve the low-power spindle drive, coolant pump, chip conveyor, or auxiliary axes. A failed inverter immediately halts the controlled function in an uncontrolled manner: without it the motor cannot start or vary its speed, rendering the served machine section completely inoperative.

FUJI Electric Co., Ltd. is a leading Japanese power electronics manufacturer, founded in 1923 as a joint venture between Furukawa Electric and Siemens. The FRENIC inverter family covers power ratings from a few watts to hundreds of kilowatts and is deployed worldwide in CNC, HVAC, and industrial automation applications. Models from the M3 series and contemporaneous variants are to be regarded as legacy / discontinued: available only as used, surplus, or through specialist repair.

Main Technical Specifications

AC Spindle Drive – FUJI FMD-11AC-21A

The FMD-11AC-21A is an AC spindle drive (“AC Spindle Drive”) from the FRENIC 5000M2 series by Fuji Electric. Designed specifically for vector speed and torque control of AC spindle motors on CNC machine tools, it sits between the mains supply and the spindle motor, converting fixed mains voltage into variable voltage and frequency. The prefix FMD identifies the spindle drive family within the FRENIC 5000M2 series; the numeric designation encodes the power class (~11 kW), AC indicates alternating-current technology, and 21A specifies the voltage variant (200 V class) and hardware revision. The unit may exist in multiple revisions and variants; option modules such as serial communication boards, EMI filters and encoder interface cards were available as separate accessories.

The AC spindle drive is the electronic core of the spindle speed control system in the machine tool: it receives the speed reference from the CNC, closes the speed and torque loop via encoder or tachogenerator feedback, and supplies the motor with the power required to hold the programmed speed constant under varying cutting loads. Failure of this unit causes immediate spindle shutdown and total machine downtime: no machining is possible until the drive is replaced or repaired, with consequent production losses and risk of scrapped workpieces.

Fuji Electric is a Japanese industrial group founded in 1923 and a world leader in the design and manufacture of AC/DC drives, inverters and industrial automation systems for precision applications. The FRENIC 5000M2 series belongs to the generation of CNC machine-tool spindle drives from the 1990s–2000s and is now legacy / discontinued: spare units are available only as used, NOS surplus, or through specialist repair centres.

Main Technical Specifications

Positioning Control Board – FUJI EP-3358C-C

The EP-3358C-C is an electronic positioning control board (“Positioning Control Board”) manufactured by FUJI Electric, designed for use in CNC systems and industrial automation equipment of the same make. The board handles axis position control and feedback processing from encoders or resolvers, interfacing with the servo drives within the same control system. It is not a CPU or generic I/O module, but a dedicated unit for precise machine axis positioning.

The positioning board is the electronic module that closes the position loop in the CNC system: it processes axis encoder feedback signals, calculates position error, and generates correction references for the servo drives. Without it, precise axis positioning is impossible: any machining operation requiring tight geometric tolerances would produce out-of-tolerance parts or risk collisions due to position reference errors.

FUJI Electric is a Japanese manufacturer with over a century of history in industrial electronics, founded in 1923 as a joint venture between Furukawa Electric and Siemens. Specialised in power electronics, drives, CNC systems and factory automation (FA), its product lines include the FRENIC inverter series and Alpha servo systems. Products in the EP-3358C-C family belong to a legacy / discontinued generation of controls and are available only as used units, NOS stock, or through specialist repair services.

Main Technical Specifications

Axis Positioning Control Board – FUJI EP-3308D-C

The EP-3308D-C is an electronic axis positioning control board (“Axis Positioning Control Board”) manufactured by FUJI Electric, belonging to the numerical control and industrial automation product family of the same manufacturer. The board processes position commands from the CNC CPU, compares them with axis encoder feedback signals, and calculates the speed reference to be transmitted to the drives. The series identifier EP-3308 designates the board family within FUJI’s positioning control range for this generation; the suffix identifies variant D and revision C.

The axis positioning board is the central element of motion control: it receives position commands from the CNC processor, compares them with the feedback signal (encoder or resolver), and calculates the following error to continuously correct the axis trajectory. Without this board, the CNC system loses complete control of the axes: any movement becomes uncontrolled, with consequent risk of collision, dimensional rejection of the workpiece, or serious mechanical damage to the machine.

FUJI Electric is a Japanese industrial group founded in 1923, with strong specialisation in power electronics, inverters, drives, CNC systems and industrial automation. Historically present in the machine tool market with proprietary axis control systems, the group has progressively oriented its offering towards new-generation integrated solutions. The CNC control modules and boards of this series are legacy / discontinued: available exclusively as used, surplus or through specialist repair.

Main Technical Specifications

Variable Frequency Inverter Drive – FUJI FRN018M3-21

The FRN018M3-21 is a variable frequency inverter drive (“Variable Frequency Drive” – VFD) from the FRENIC® series, manufactured by FUJI Electric. The unit is designed for scalar (V/f) or vector control of three-phase asynchronous motors in industrial applications, and is documented in CNC systems and machine tools as a spindle drive or feed-axis drive. The designation FRN018M3-21 identifies: prefix FRN (FRENIC family), nominal rating 018, series M3 (FRENIC-5000 M, third generation), suffix 21 (voltage/configuration code: 200 V class). The unit may exist in hardware revision variants; optional accessories such as a remote operator panel and EMC filters may not be included in the standard supply.

The variable frequency drive is the component that regulates the rotation speed of an asynchronous motor by continuously varying the supply frequency and voltage: in a CNC machining centre it controls the spindle (cutting speed) or the feed axes (feed rate). Failure of the drive causes the immediate stop of the controlled axis or spindle, rendering the machine completely inoperable until the module is replaced or repaired.

FUJI Electric Co., Ltd. is a Japanese multinational founded in 1923 as a joint venture between Furukawa Electric and Siemens, specialising in electric drives, power components, UPS systems and industrial automation. The FRENIC series is Fuji’s historic line of industrial inverters, evolved from the FRENIC-5000 through to the current FRENIC-Ace and FRENIC-AQUA. All products in the FRENIC-5000 M family are legacy / discontinued: available exclusively as used stock, NOS (new-old-stock) or through specialist repair services.

Main Technical Specifications

AC Inverter FRENIC 5000P11 15 kW – FUJI FRN15P11S-2

The FRN15P11S-2 is a 15 kW AC variable frequency drive (VFD – “AC Variable Speed Drive”) belonging to the FRENIC 5000P11 series, manufactured by FUJI Electric and rated for the 200 V three-phase voltage class. The unit implements V/f control and, in advanced variants, sensorless vector control of three-phase induction motors. It is documented as a drive component in numerous CNC machining centres and industrial machines from the 1990s and 2000s equipped with FUJI P11-series inverters. The control connector is a standard multi-pin terminal strip compatible with the entire FRENIC 5000P11 product family.

The FRENIC 5000P11 inverter converts mains voltage to variable-frequency AC, enabling precise speed and torque control of the connected induction motor. In a CNC machining centre, its failure renders the controlled axis or spindle inoperative: production stops and no controlled movement is possible. Replacement with a different model requires full parameter reconfiguration and verification of analogue and digital control signal compatibility.

FUJI Electric is a Japanese manufacturer founded in 1923, a world leader in frequency converters, power equipment, and industrial automation systems. The FRENIC 5000P11 series was commercialised from the late 1990s; the model is now classified as legacy / discontinued and is no longer directly supported by the manufacturer: availability is limited to used stock, surplus parts, and specialist repair services.

Main Technical Specifications

1.5 kW General-Purpose Inverter – FUJI FRN1.5G9S-2

The FRN1.5G9S-2 is a variable frequency drive (VFD) (“Variable Frequency Drive”) from the FRENIC 5000G9S series by FUJI Electric, rated at 1.5 kW with a 200 V class three-phase input. The G9S designation identifies the ninth generation of the General Purpose series; the suffix “2” denotes the 200 V AC voltage class. The unit implements sinusoidal PWM modulation with V/f law and sensorless vector control, and is documented as a drive for three-phase induction motors in machine tool installations, conveyor lines, and CNC auxiliary systems. No significant hardware revisions are known for this power rating; no optional accessories are included as standard.

The inverter regulates the speed and torque of the electric motor by continuously varying the output frequency and voltage: it receives the speed reference from the CNC (analogue ±10 V or digital) and provides controlled acceleration/deceleration ramps, overcurrent protection, and overtemperature protection. A failed inverter causes the controlled motor to stop and prevents restart: on a CNC axis or spindle this results in an immediate machine halt, loss of production, and potential dimensional rejects on the workpiece in progress.

FUJI Electric is a Japanese industrial group founded in 1923, specialising in electric drives, power systems, and factory automation; the brand is globally recognised for the reliability of its inverters in industrial applications. The FRENIC 5000G9S series represents one of FUJI’s general-purpose inverter generations from the 1990s; current FUJI production focuses on the FRENIC-Ace and FRENIC-MEGA families. The FRN1.5G9S-2 belongs to a legacy / discontinued product family: available exclusively as used, NOS (New Old Stock), or through specialist repair services.

Main Technical Specifications

CNC Power Supply Unit – HEIDENHAIN UVR 140D

The UVR 140D is a CNC power supply unit (“CNC Power Supply Unit”) manufactured by HEIDENHAIN, designed to provide the regulated DC voltages required for the operation of HEIDENHAIN CNC control systems. The unit converts the AC mains voltage into one or more stabilised low-voltage DC outputs, powering the control logic, axis boards and peripheral modules of the system. Typically used in HEIDENHAIN TNC series numerical controls from the 1980s and 1990s, including the TNC 150, TNC 155 and contemporary variants.

The power supply unit is the energy core of the CNC system: without stable, regulated voltages the control cannot start up, the axis boards cannot operate and the encoder measurement system loses its reference supply. A power supply failure typically manifests as sudden control shutdown, power error messages or axis position instability, rendering the machine completely unusable until the component is replaced or repaired.

HEIDENHAIN (Johannes Heidenhain GmbH) is a German company founded in 1889 in Traunreut, a world leader in the manufacture of linear and rotary encoders, precision measurement systems and CNC numerical controls for machine tools. Power supply components from the TNC series of the analogue era and early digital systems are today legacy / discontinued: available exclusively as used parts, reconditioned units, or through specialist repair centres.

Main Technical Specifications

Servo Drive Module – HEIDENHAIN UM 115D

The UM 115D is a servo drive module (“Servo Drive Module” / Umrichter) manufactured by HEIDENHAIN, belonging to the modular drive family for linear and rotary axes in CNC machine tools equipped with HEIDENHAIN TNC controls (e.g. TNC 150, TNC 155, TNC 407/410/415). The catalog code is UM 115D (internal identifier UM115D). The prefix “UM” derives from the German Umrichter (inverter / drive); the suffix “D” identifies a specific variant of the series, likely related to the nominal input supply voltage (~115 V AC) or a design revision. The module fits into the backplane or rack of the control cabinet and receives position/speed references from the CNC via the proprietary HEIDENHAIN bus.

The servo drive is the core of the axis control loop: it receives the position and speed setpoint from the CNC unit, closes the current and velocity loop on the servo motor, and ensures each axis performs movements with the micron-level precision required during machining. A drive failure completely disables the corresponding axis — the machine triggers an alarm, the axis stops responding to commands and the machining cycle cannot continue. Timely replacement or repair is therefore essential to restore production.

HEIDENHAIN is a German company founded in 1889 in Traunreut (Bavaria), a world leader in position measurement technology (optical scales, rotary and angle encoders) and CNC controls of the TNC series. The drive product line has been progressively updated; modules of the UM series belong to a legacy / discontinued generation, no longer supplied directly by HEIDENHAIN but still supported by specialist repair centres and available as used/surplus on the secondary market.

Main Technical Specifications

Servo Drive Module – HEIDENHAIN UM 112D

The UM 112D is an analogue servo drive amplifier module (“Servo Drive Amplifier Module”) manufactured by HEIDENHAIN, documented as a component of HEIDENHAIN CNC systems based on the TNC series controls (TNC 155, TNC 360, TNC 407 and compatible systems). The module receives an analogue speed reference from the numerical control and drives the axis servo motor, closing the position/speed loop via feedback from a HEIDENHAIN encoder. The UM family covers several current-rating variants; the suffix D identifies the specific revision or sub-variant of this module.

The servo drive module is the electronic heart of the axis regulation loop: it amplifies the CNC reference signal and converts electrical power into torque on the servo motor, ensuring precise positioning and controlled motion dynamics. A failure of the module renders the corresponding axis inoperable, halting the machine and requiring immediate replacement to restore production.

HEIDENHAIN is a German company founded in 1889, a world leader in the production of position measurement systems (linear and rotary encoders), numerical controls (TNC series) and drives for precision machine tools. The UM series modules belong to the analogue-generation HEIDENHAIN drives and are today legacy / discontinued: support is only available through used spare parts or specialist repair services.

Main Technical Specifications

Servo Drive Module – HEIDENHAIN UM 111

The UM 111 is a servo drive module (“Servo Drive Module” / Vorschubumrichter) manufactured by HEIDENHAIN, documented as a feed axis drive component for milling machines and machining centres equipped with HEIDENHAIN TNC CNC controls (series TNC 145, TNC 155, TNC 360 and related generations). The module manages the current and speed regulation loops of the DC servo motor, interfacing with the CNC unit via the speed reference bus. It is not a CPU board or I/O module, but a dedicated drive for linear axis control.

The UM 111 is the electronic drive that closes the current and speed loop on the feed axis servo motor: it receives the speed reference from the HEIDENHAIN TNC controller and supplies the motor with precisely controlled current, ensuring accurate positioning and interpolation. In the event of failure, the CNC triggers an axis alarm and the machine stops completely; without this module no programmed feed motion is possible.

HEIDENHAIN (Dr. Johannes Heidenhain GmbH) is a German precision technology manufacturer founded in 1889, headquartered in Traunreut, Bavaria, specialising in linear and rotary encoders, CNC controls (TNC series) and drive systems. The company remains independent and active. Products in the UM series are legacy / discontinued components associated with TNC control generations of the 1980s–1990s, available exclusively as used, surplus, or through specialist repair.

Main Technical Specifications

2-Axis Control Module – HEIDENHAIN UM121B

The UM121B is a 2-axis control module (“2-Axis Control Module”) manufactured by HEIDENHAIN, a component of the modular CNC control systems of the TNC series (typically TNC 155 / TNC 355 and derivatives). The module manages position and velocity loops for two servo axes, processing incremental encoder signals from HEIDENHAIN encoders and generating torque references to the drive power stages. The “B” variant identifies a specific hardware revision; the module plugs into the CNC chassis via a card-edge connector.

The 2-axis module is the core of the CNC position controller: it acquires real-time feedback from the linear or rotary encoders on both assigned axes and closes the control loop, ensuring that the programmed path is followed with the micron-level precision characteristic of HEIDENHAIN systems. In the event of failure the control immediately raises an alarm and locks the two affected axes: no machining is possible until the module is replaced or repaired, making it a strictly critical component for production continuity.

HEIDENHAIN (Dr. Johannes Heidenhain GmbH) is a German precision technology company founded in 1889, a world leader in linear and rotary encoders, glass scale measurement systems, and CNC controls for high-precision machine tools. The TNC series controls are installed on machining centres, milling machines, and grinding machines worldwide. Modules in the UM family are legacy / discontinued: available only as used, surplus, or through specialist repair services.

Main Technical Specifications

PLC Expansion Board – HEIDENHAIN PL 410B

The PL 410B is a PLC expansion board (“PLC Expansion Board”) manufactured by HEIDENHAIN, designed to extend the digital input/output capabilities of TNC-series CNC controls (typically TNC 360, TNC 415, TNC 425 and compatible variants). The board integrates into the control system via ribbon cable or backplane connector and handles bidirectional digital signals between the control and the machine tool’s peripheral devices: limit switches, proximity sensors, actuators and solenoid valves. The “B” suffix identifies a specific hardware revision of the board.

The PLC expansion board is the physical interface between the HEIDENHAIN control’s PLC program and the machine’s real-world devices: it reads the status of inputs (limit switches, sensors, cycle push-buttons) and switches outputs (relays, valves, indicator lights). If the board fails, the CNC control loses its ability to manage machine logic: axes latch in safe-stop, automatic cycles cannot execute, and PLC alarms render the machine completely inoperable until the module is replaced or repaired.

HEIDENHAIN is a German company founded in 1948, a world leader in linear and rotary encoders, measurement systems and CNC controls for precision machine tools. Remaining independent, it is internationally recognised for the reliability and accuracy of its systems. Modules in the PL 410 series belong to a generation of controls that is now legacy / discontinued: availability is limited to the used market and specialist repair.

Main Technical Specifications

PLC I/O Board – HEIDENHAIN PL 300

The PL 300 is a PLC input/output expansion board (“PLC I/O Board”) manufactured by HEIDENHAIN, documented as an expansion module for HEIDENHAIN TNC series CNC control systems (e.g. TNC 360, TNC 415, TNC 425). It manages the interface between the CNC control unit and the machine tool’s peripheral devices: limit switches, sensors, solenoid valves, and actuators. It is not a CPU or a drive, but a dedicated PLC I/O expansion module.

The PLC I/O board is the digital bridge between the CNC control and the machine: it acquires input signals from limit switches, pushbuttons, and process sensors, and generates output commands for solenoid valves, relays, lubrication systems, and automatic tool changers. A failure of this module causes partial or total loss of control over machine peripherals, resulting in immediate production downtime and inability to safely execute automatic machining cycles.

HEIDENHAIN (Dr. Johannes Heidenhain GmbH) is a German company founded in 1948 in Traunreut, Bavaria, specializing in precision measurement systems (linear and rotary encoders, digital readouts) and CNC controls for machine tools (TNC series). Remaining family-owned and independent, it is one of the world’s leading manufacturers in the field. The PL 300 module belongs to a legacy / discontinued product family: available only as used, surplus, or through specialist repair.

Main Technical Specifications

LCD Operator Panel – HEIDENHAIN BF 370

The BF 370 is an LCD operator panel (“LCD Operator Panel”) manufactured by HEIDENHAIN, designed as a human-machine interface unit for TNC series CNC controls (compatible with TNC 410, TNC 415, TNC 426, TNC 430 and related controllers). It integrates a colour TFT display, a keyboard with function keys, configurable softkeys, a numeric keypad, and axis selection keys, connecting to the CNC control unit via the proprietary HEIDENHAIN cable harness. It does not include an autonomous processing unit: it is a display and data-entry terminal dependent on the main controller.

The operator panel is the primary human-machine interface of the CNC machining centre: it displays part programs, machining data, diagnostic messages, and graphical tool-path simulations, allowing the operator to input programs, monitor the machining cycle, and set tool offsets. In the event of failure, the machine becomes completely inaccessible for programming and manual operation, making this component a critical production bottleneck.

HEIDENHAIN (Dr. Johannes Heidenhain GmbH) is a German precision technology company founded in 1889, headquartered in Traunreut, Bavaria, specialising in linear and rotary encoders, measuring systems, and CNC controls for machine tools. The TNC series has been the industry reference standard for high-precision milling and machining centre control for decades. Operator panels of the BF generation are now legacy / discontinued: available only as used, surplus, or through specialist repair services.

Main Technical Specifications

CNC Power Supply Module – HEIDENHAIN 289 133-15

The 289 133-15 is a power supply module (“Power Supply Unit”) manufactured by HEIDENHAIN, installed inside the cabinet of HEIDENHAIN computerised numerical control systems (TNC series). The unit generates and distributes the regulated DC voltages required by the control logic, encoder interfaces, and auxiliary circuits of the CNC. It is not a drive or a CPU board: its sole function is to power the system electronics. No additional accessories are normally included in the standard supply.

The power supply is the energy core of the control system: it converts mains voltage into regulated DC voltages that are indispensable for the CPU, interfaces, servo drives, and CNC peripherals. A power supply failure causes an immediate and complete machine shutdown; without it no axis can be moved and no program can be executed, resulting in total production stoppage.

HEIDENHAIN (Dr. Johannes Heidenhain GmbH) is a German company founded in 1948 in Traunreut, Bavaria, and a world leader in the manufacture of optical linear and rotary encoders, precision measurement systems, and numerical controls for machine tools (TNC series). Its products are synonymous with extremely high precision and reliability in precision machining. Components from older control generations (TNC 155, TNC 360, TNC 407/410/415/425) are legacy / discontinued and available only as used parts, surplus stock, or through specialist repair.

Main Technical Specifications

CNC Electronic Control Board – HEIDENHAIN 238 289 01

The 238 289 01 is an electronic control board (“Electronic Control Board”) manufactured by HEIDENHAIN, a leading German manufacturer of precision measurement and CNC control systems. The component belongs to the internal control electronics family of HEIDENHAIN TNC control systems, designed for signal management and interfacing within the control unit. The part number includes a hardware revision suffix (01) identifying the specific board variant; later revisions may exist. The board is installed in the control’s electronics rack and operates in conjunction with the other cards on the TNC backplane.

HEIDENHAIN TNC internal electronic boards perform essential functions: processing position signals from encoders, managing interpolated axes, interfacing with the power electronics, and handling inter-module communication within the CNC. A failure of this component typically causes a complete or partial control shutdown — unexpected machine stops, loss of position reference, or system errors that make machining impossible until the board is replaced or repaired.

HEIDENHAIN (Dr. Johannes Heidenhain GmbH) is a German company founded in 1948 in Traunreut, Bavaria, specialising in position measurement systems (linear and rotary encoders, optical scales), TNC numerical controls, and precision instrumentation for machine tools. Unlike many competitors, HEIDENHAIN has remained independent and is still active; however, boards in the 238 xxx series belong to control generations that are now legacy / discontinued and are available only as used stock, NOS surplus, or through specialist repair services.

Main Technical Specifications

CNC Control Electronic Board – HEIDENHAIN 237 930 01

The 237 930 01 is a CNC control electronic board (“CNC Control Board”) manufactured by HEIDENHAIN, belonging to the component family for TNC numerical control systems in the legacy series. It is designed to operate inside the control cabinet of CNC milling machining centres or equivalent systems equipped with a HEIDENHAIN control. It performs processing, interface, or axis management functions depending on the system in which it is installed; the specific function must be verified in the technical documentation of the reference machine. The component belongs to the historical HEIDENHAIN production line, with no officially documented revisions or variants on the secondary market.

Electronic boards in HEIDENHAIN CNC systems form the processing and interface core of the numerical control: they manage communication between the computing unit, servo drives, position encoders, and operator interface. A failure on this board results in an immediate machine halt, positioning errors, loss of communication with the axes, or inability to start the machining cycle — production downtime that cannot be recovered without replacement or repair of the component.

HEIDENHAIN (Dr. Johannes Heidenhain GmbH) is a German company founded in 1889, a world leader in the production of position measurement systems — linear, rotary and angle encoders — and TNC series CNC numerical controls, used primarily on milling machines, machining centres, and high-precision grinding machines. Products from the TNC 2500 generation and contemporary series are legacy / discontinued: available exclusively as used components, NOS (New Old Stock), or through specialist repair.

Main Technical Specifications

Power Supply Unit for CNC Control – HEIDENHAIN 236 484 10

The 236 484 10 is a multi-rail switching power supply unit for CNC control systems (“Power Supply Unit”) manufactured by HEIDENHAIN (Dr. Johannes Heidenhain GmbH, Traunreut, Germany). The module converts mains voltage into stabilised multi-rail DC output (±15 V, +5 V, +24 V typical), distributed to logic boards, encoder interfaces and I/O modules inside the control unit. The part is documented as a component of HEIDENHAIN TNC-series analogue–digital CNC controls (typically TNC 155, TNC 360 and derivatives) and coeval measuring systems and digital readouts. The product belongs to the power supply line from the 1980s–1990s generation; no publicly documented revision variants are known.

The power supply is the energy core of the CNC control: without stable, noise-free supply voltages no logic board, encoder interface or I/O module can operate correctly. A power supply failure typically manifests as a complete control lockout, undiagnosable system errors, spontaneous resets or corrupted measurement data. Replacement with a genuine HEIDENHAIN module is the only intervention that guarantees full restoration of machine functionality.

HEIDENHAIN (Dr. Johannes Heidenhain GmbH) is a German company founded in 1948 in Traunreut (Bavaria), a world leader in precision measurement systems (linear encoders, rotary encoders, optical measuring scales) and TNC-series CNC controls, the de facto standard for precision milling and grinding. All products belonging to this generation are legacy / discontinued: no longer available new from the manufacturer and sourced exclusively as used stock, NOS (new old stock) or through specialist repair services.

Main Technical Specifications

Power Supply Unit for CNC Control Systems – HEIDENHAIN 236 484 02

The 236 484 02 is a power supply module for CNC control and position display systems (“Power Supply Unit”) manufactured by HEIDENHAIN, documented as a power supply component for units in the TNC (numerical control) and/or ND (position display) product range. The module converts and regulates the mains voltage, providing the stabilised DC voltages required by the control electronics, encoder modules and logic boards of the system. The suffix -02 identifies the revision or output configuration variant relative to the base article.

The power supply is the critical component that ensures the stability and quality of the electrical energy distributed to all subsystems of the CNC control: from processing logic to encoder and motor interfaces. A power supply failure causes the immediate shutdown of the control unit, resulting in total machine downtime; unregulated or noisy voltages can cause encoder reading errors, loss of position and damage to sensitive downstream circuits.

HEIDENHAIN (“Dr. Johannes Heidenhain GmbH”) is a German company founded in 1948 in Traunreut (Bavaria), a world leader in the manufacture of high-precision linear and rotary encoders, optical scales, TNC-series CNC numerical controls and industrial measurement systems. Still an independent, active company, HEIDENHAIN products are fitted on leading machine tool builders (Hermle, DMG Mori, Deckel Maho, Mikron, etc.). Components belonging to the older TNC and ND series are legacy / discontinued: available only as used, surplus or through specialist repair.

Main Technical Specifications
